Processing Range |
φ1.6-φ120mm
Max Length of Cut-in Mill200mm |
|
Motor |
For Grinding Wheel11kW 4P
For Guide Wheel1.5kW 6P
For Cooling0.25kW 2P |
|
Spindle Unit |
Spindle Roller Bearing Cantilever Support Type Grinding Wheel
Spindle Roller Bearing Double Support Type Guiding Wheel |
|
Specification of Grinding Wheel |
610×205×304.8mm(Outer Diameter×Width×Bore Diameter) |
|
Specification of Guide Wheel |
330×205×203.2mm(Outer Diameter×Width×Bore Diameter) |
|
Rotational Speed |
Grinding Wheel 1400rpm(MAX.1875rpm)
Linear Speed 45m/s(MAX.60m/s)
Stepless Variable-frequency Speed Regulation of Guiding Wheel12-230rpm |
|
Electric Control Device |
Mitsubishi PLC Products |
|
Power Supply Voltage |
AC380V, Frequency 50Hz |
|
Control Voltage |
AC100V/110V;DC24V |
|
Tilting Angle of Guide Wheel |
﹢5°-﹣5° |
|
Floor Area |
3050×2700mm(Width×Length) |
|
Machine Tool Weight |
About 7t |
